M8 3-Pin Female Connector PVC Cable IEC 61076-2-104 Straight

Name: M8 3Pin Female Connector PVC Cable IEC 610762104 Straight
Brand: KRONZ
Price: 1 USD

Quality M8 3-Pin Female Connector PVC Cable IEC 61076-2-104 Straight for sale

Brand Name : KRONZ

Model Number : M0803F-2/POOR

Certification : CE

Place of Origin : Guangdong, China

MOQ : 50 pieces

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 100000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Price : Negotiable

Type : Contact

Product name : M8 Pre-Assembled Cable Connector

Contact carrier material : PA, black

Housing material : TPU, black

Seal material : FPM/FKM

Contact resistance : ≤ 5mΩ

Pollution degree : 3

Endurance(shell) : >100 cycles

Contact Now

M8 Pre-assembled Connector PVC Cable IEC 61076-2-104 Straight Female 3 Pin A Code

This pre-assembled M8 3-Pin Female Connector with a straight head and PVC cable offers a reliable, ready-to-use solution for connecting sensors, actuators, and field devices in industrial automation systems. Built to IEC 61076-2-104 standards, it ensures secure and standardized connectivity with excellent resistance to vibration, moisture, and mechanical stress.

Features:

Connector Type: M8 Circular Connector – Female, 3-Pin
Orientation: Straight (in-line)
Pre-Assembled Cable: PVC-jacketed, flexible, oil-resistant
Pin Coding: A-Coded (standard for signal and sensor applications)
Standard Compliance: IEC 61076-2-104
Ingress Protection: IP67 (when mated) – waterproof and dustproof
Cable Length Options: Commonly available from 1m to 10m (custom lengths on request)
Rated Voltage: Up to 60V AC/DC
Rated Current: Up to 4A
Contact Material: Gold-plated contacts for reliable conductivity
Temperature Range: -25°C to +80°C
Cable Diameter: Typically 4–5 mm
Bend Radius: Approx. 5× cable diameter (static)

Product Dimension

M8 3-Pin Female Connector PVC Cable IEC 61076-2-104 Straight

Product Images

M8 3-Pin Female Connector PVC Cable IEC 61076-2-104 Straight

Technical Parameters

Standard	IEC 61076-2-104
Contact nut material	Brass, nickle-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	TPU, black
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP67

Pin assignment	Wire color	Coding	Rated current	Voltage	Wire gauge	Cable outlet	Length	Model No.
	1=BN 3=BU 4=BK	A	3A	60V	3x0.25 (3x24AWG) PVC, black	Straight	2M	M0803M-2/POOR
							5M	M0803M-5/POOR
							10M	M0803M-10/POOR

Application

M8 pre-molded cable connectors have a wide range of applications in the industrial field, particularly in industrial robot control systems. They are commonly used to connect industrial robots to control systems, allowing robots to receive input signals from sensors and output control signals, thereby enabling precise motion control. M8 connectors can withstand high vibrations, temperature variations, and other extreme environmental conditions, ensuring the efficient and stable operation of robots on the production line.
